ComAp InteliGen NT®
InteliGenNT is a comprehensive controller for both single and multiple gen-sets operating in standby or parallel modes. Compact construction is optimized for these purposes and various HW modifications allow customers to select the optimum type for a particular application.
A built-in synchronizer and digital isochronous load sharer allow a total integrated solution for gen-sets in standby, island parallel or mains parallel. Native cooperation of up to 32 gen-sets is a standard feature.
InteliGenNT supports many standard ECU types and is specially designed to easily integrate new ones.
A powerful graphic display with user-friendly controls allows any user whatever their ability to find the information they need.
T-Rod Energy Electromech is able to offer customized firmware solutions.
T-Rod Energy Electromech also has a marine version of the InteliGenNT available for use in maritime applications. The InteliGenNT Marine has the same features as the InteliGenNT, but is approved for use in marine environments by DNV, GL, Lloyds Register and CRS classification and registration bodies.
| FEATURES |
|---|
| Support of engines with ECU (J1939, Modbus and other proprietary interfaces); alarm codes displayed in text form |
| AMF function |
| Automatic synchronizing and power control (via speed governor or ECU) |
| Baseload, Import/Export |
| Peak shaving |
| Voltage and PF control (AVR) |
| Generator measurement: U, I, Hz, kW, kVAr, kVA, PF, kWh, kVAhr |
| Mains measurement: U, I, Hz, kW, kVAr, PF |
| Inputs and outputs configurable for various customer needs |
| Controller redundancy |
| RS232/RS485 interface with Modbus support; Analog/GSM/ISDN/CDMA modem support; SMS messages; ECU Modbus interface |
| Event-based history (up to 500 records) with customer-selectable list of stored values; RTC; statistic values |
| Integrated PLC programmable functions |
| Interface to remote display unit (IG-Display LT GC) |
| Dimensions 180×120 mm (front panel) |
| Sealed to IP65 |
| Additional 160 programmable protections configurable for any measured value to create customer-specific protections |
| Application security |
| BENEFITS |
|---|
| Support of engines with ECU (Electronic Control Unit) |
| Complete integrated gen-set solution and signal sharing via CAN bus – minimum external components needed |
| Many communication options – easy remote supervising and servicing |
| Perfect price/performance ratio |
| Gen-set performance log for easy problem tracing |
| Built-in PLC function |
